Choose from the following options; Type B depositor without a hopper Belshaw Type B Cake Donut Depositor with a Hopper Belshaw Type B Cake Donut Depositor with a hopper and the mounting column for the fryer Belshaw Type B Cake Donut Depositor with a hopper and the mounting system for the wall *All of the options need a cylinder and choice of plungers to be complete. Belshaw Type B depositors, the industry standard for many years, are legendary for their precision and smoothness of operation - even after years of use in harsh conditions. Each depositor is engineered to ensure identical volume and shape are produced with each and every deposit. The service life of a Type B depositor is frequently measured in decades! The Type B Depositor uses a hand crank to deposit at a rate of 60-100 (or more) per minute. An adjustment dial allows a wide range of deposit sizes Hopper capacity is 15 lbs (7 kg). Choose from the depositor accessories for: Plungers - for ring donuts, sticks, old fashions, crullers, krinkles and more. Cylinders - any plunger used must be matched by a cylinder of the same size. This cylinder is inserted into the bottom of the hopper. One cylinder can be used with several plungers, as long as the plungers are all the same size as the cylinder. Column Mount or Wall Mount - Type B is compatible with most floor-standing fryers using either a column mount attached to the fryer or a secure wall mount. The column mount is more convenient and more common and will fit Belshaw Adamatic fryers and some other brands. Consult with other brand manufacturers to find out how to combine with a Type B. If a column mount is not possible, a well secured wall mount is a good alternative. The Bracket Arm Height Adjuster is another useful option for easier, more convenient height adjustments. (See depositor accessories)

Type F-YRD Belshaw Raised Donut Depositor from Belshaw on Vimeo. Belshaw Adamatic's Type F depositors operate with the same accuracy and smoothness as Type B depositors, but use an electric motor and trigger handle to deposit cake donuts. The faster stroke rate and easier operation of the Type F reduces frying time variability between the first and last deposits, especially with large fryers. The hand trigger is physically easier on the operator than the Type B's rotary crank mechanism, and donuts can be accurately placed in a fryer with little training or practice.   Deposits approximately 115 cake donuts per minute when the trigger is pressed continuously. An adjustment dial allows a wide range of deposit sizesHopper capacity is 15 lbs (7 kg). Choose from the depositor accessories for: Plungers - for ring donuts, sticks, old fashions, crullers, krinkles and more. Cylinders - any plunger used must be matched by a cylinder of the same size. This cylinder is inserted into the bottom of the hopper. One cylinder can be used with several plungers, as long as the plungers are all the same size as the cylinder. Column Mount or Wall Mount - Type F is compatible with most floor-standing fryers using either a column mount attached to the fryer or a secure wall mount. The column mount is more convenient and more common and will fit Belshaw Adamatic fryers and some other brands. Consult with other brand manufacturers to find out how to combine with a Type F. If a column mount is not possible, a well secured wall mount is a good alternative. The Bracket Arm Height Adjuster is another useful option for easier, more convenient height adjustments. (See depositor accessories)

THE QUICK, NO FUSS METHOD OF MAKING WELL FORMED CAKE DONUTS. Choose the model with 1-9/16 inch size plunger for standard size donuts, or 1-inch plunger for mini donuts The handheld Type K Donut Depositor is ideal for smaller fryers such as Belshaw Adamatic 616B. One hopper holds 5.5 lbs (2.2 kg) and turns out about 5 dozen average size donuts. 6 volume settings can be selected on the handle. Typical weight range is from 1.2 - 1.8 oz. (34 - 50g), making a variety of donut sizes possible. A consistently shaped product is delivered time after time. Type K Donut Depositor (Item #8504022) includes a 1-9/16" plunger for standard size Ring Donuts. In addition the Donut Depositor accepts 3 optional attachments to a plain plunger. These attachments divide the donut deposit into 2, 3 or 4 pieces (see the options page). The entire unit is corrosion resistant and easy to clean. The Type K Donut Depositor is NSF-certified. An convenient stand is available as an option.

The easiest way to deposit Southern Fried Hushpuppies with smaller fryers. Belshaw's Type K Hushpuppy Depositor is ideal for depositing Southern Fried Hushpuppies with smaller fryers such as Belshaw's 616B. The Type K is quick and easy to use, and designed to be mastered by a novice in minutes. Operation is easily accomplished with minimal waste, and consistent deposits can be delivered time after time. The Type K Hushpuppy Depositor deposits 2 generous size hushpuppies for each push of the handle. There are 8 deposit size settings located on the handle with weight range from approximately 10 to 24 grams. Hopper size is generous and holds about 5.5 pounds of batter. Each hopper is constructed of aluminum; each plunger and cylinder is constructed of stainless steel. The entire unit is corrosion resistant and easy to clean. The Type K Hushpuppy Depositor is NSF-C2 certified. A convenient holder is available as an option.  Stand sold separately

SUPPORTS TYPE B OR F CAKE DONUT DEPOSITORS The column mount attaches directly to your Floor Model Fryer Product Description; The Column Mounting Kit supports Type B or F cake donut depositors. The column is usually mounted on the left side of a Belshaw Adamatic fryer. For mounting on the right, the Bracket Plate can be moved from the left to the right side. Other fryers may accept the Column Mount if suitably strengthened (contact manufacturer) or if they will accept a Bracket Plate kit. Fryer must be bolted to the floor. The full extension of the column mount is 42"/105cm, from the column to the actual donut drop.

Stand is not included; TYPE K PANCAKE DISPENSER The Professional's favorite for accurately portioned, cleanly dispensed Pancake and Waffle batter. When it comes to making dozens, even hundreds of pancakes, Belshaw's Type K Pancake Dispenser is the professional's choice. The Type K is quick and easy to use and provides accurate portion control at a variety of sizes, from mini to extra large. Belshaw's Type K depositors are designed to be mastered by the novice in minutes. Operation is easily accomplished with minimal waste, and consistent deposits can be delivered time after time. Each pancake dispenser offers 8 size settings located on the handle. Hopper size is generous and holds about 5.5 pounds (2.5 kg). The Type K hopper is aluminum to save weight. Plunger and built-in cylinder are stainless steel for durability. The entire unit is corrosion resistant and easy to clean. The Type K Pancake Dispenser is NSF-C2 certified. A convenient holder is available as an option.   Item # 8504011 Type K Pancake Depositor

Belshaw Type N Wall Mount   Parts# N-1036 The Wall Mount attaches your depositor to the wall behind your fryer. The installation must be very dependable and secure. If you move the fryer, you must re-install the Wall Mount. It is sometimes a good solution if a Type N depositor is combined with a different fryer.  A simple Lock Collar is supplied with both Mounting Kits to set your depositor height about 1¼ to 1½" above the shortening (30-40 mm). The optional Precision Height Adjuster is useful for making faster, more accurate height adjustments. full extension 32 inches (from the mounting point to the donut deposit, center-to-center)

*This Unit Is sold without the hopper Belshaw Adamatic's Type F depositors operate with the same accuracy and smoothness as Type B depositors but use an electric motor and trigger handle to deposit cake donuts. The faster stroke rate and easier operation of the Type F reduces frying time variability between the first and last deposits, especially with large fryers. The hand trigger is physically easier on the operator than the Type B's rotary crank mechanism, and donuts can be accurately placed in a fryer with little training or practice. Deposits approximately 115 cake donuts per minute when the trigger is pressed continuously. An adjustment dial allows a wide range of deposit sizes. Hopper capacity is 15 lbs. (7 kg). Choose from the depositor accessories for: Plungers - for ring donuts, sticks, old fashions, crullers, krinkles and more. Cylinders - any plunger used must be matched by a cylinder of the same size. This cylinder is inserted into the bottom of the hopper. One cylinder can be used with several plungers, as long as the plungers are all the same size as the cylinder. Column Mount or Wall Mount - Type F is compatible with most floor-standing fryers using either a column mount attached to the fryer or a secure wall mount. The column mount is more convenient and more common and will fit Belshaw Adamatic fryers and some other brands. Consult with other brand manufacturers to find out how to combine with a Type F. If a column mount is not possible, a well secured wall mount is a good alternative. The Bracket Arm Height Adjuster is another useful option for easier, more convenient height adjustments. (See depositor accessories)

SUPPORTS TYPE B AND F CAKE DONUT DEPOSITORS ONLY The wall mount attaches securely to a wall behind your Floor Model Fryer of any make fryer Product description : The Wall Mounting Kit supports Type B or F cake donut depositors, with precision screw for adjusting the angle of the depositor. Mounts to the wall behind or alongside fryer. The full extension of the wall mount is 42"/105cm, from the wall fixture to the actual donut drop. Can be used with any make of fryer within its range of extension. The Wall Mounting Kit supports Type B or F cake donut depositors, with precision screw for adjusting the angle of the depositor. Mounts to the wall behind or alongside fryer. The full extension of the wall mount is 42"/105cm, from the wall fixture to the actual donut drop. Can be used with any make of fryer within its range of extension.

Hand-crank depositor for 616B Fryer and Cut-N-Fry *- Shown with Mounting Kits For Photos of Depositor and Hopper,  Belshaw Adamatic Type N is a rotary crank donut depositor. Type N is designed for Belshaw Cut-N-Fry for Donuts / Hushpuppies / Loukoumades, although it can be used with other frying systems if the correct mounting system is chosen. The hopper holds approximately 12lbs (5.5kg) of batter. 3 mounting systems are available Column mount with short arms - this is the mount designed for Belshaw Adamatic 616B fryer. (The combination is called a Cut-N-Fry system). Column mount with long arms - used when 2 616B fryers are used side by side. A single Type N can be used for both fryers. Wall mount with long arms - used with any fryer other than Belshaw Adamatic 616B. Cylinder and plungers are ordered separately for cake donuts, Loukoumades and hushpuppies. See accessories for details.

Replacement motor for the Belshaw Type F motor (110V).110V motor 0315J-1, Type F Replacement Motor 110V-single phase. * The motor shown in the photo may have accessories attached that you will need to use from your existing Type F motor. We removed the motor from a Type F to provide you the photo and is not a stock photo from the manufacturer.

Precision Height Adjuster for Type B/ F/ N (column mount only) Belshaw Cake Donut Depositors. This collar provides a more accurate setting of height adjustment thn the supplied set collar that comes in the column mount kit.

Bracket plate kit, used for stability if column mount is added to a Non-Belshaw fryer.
